For evaluation and development of automotive Ethernet / industrial single-pair Ethernet! 1000BASE-T1 / 100BASE-T1 compatible Media Converter

This article is an introduction page for a "1000BASE-T1 / 100BASE-T1 compatible media converter" used for evaluation and development of automotive Ethernet / industrial Single Pair Ethernet (SPE).

Additionally, you can download the "SPE Introductory Guide," which systematically covers everything from the basics of SPE to the differences between 100BASE-T1 and 1000BASE-T1, and how to build an evaluation environment.
(Download the document)

▼ Ideal for these customers ▼ ＼A popular product with a proven track record in automotive Ethernet evaluations and many repeat customers／

・While 1000BASE-T1 has begun to be adopted in ADAS and next-generation gateway development, we are having trouble connecting it directly to evaluation PCs (RJ-45).

We are considering SPE (Single Pair Ethernet) to reduce wiring in industrial equipment, but there is no readily available evaluation environment.

We have evaluation equipment for 100BASE-T1, but we now need equipment that can also handle 1000BASE-T1. ...etc.

▼ Customer Feedback ▼

"Extremely convenient for debugging and testing!" "Easy to check signal quality and link speed!" "Now an indispensable tool for automotive Ethernet evaluation!"

It's incredibly simple and easy to use! 5 key features

Used in automotive networks and industrial single-pair Ethernet.
	1. Compliant with IEEE 802.3bp / 802.3bw [In-vehicle network For evaluation and development [Factory DX Accelerate wiring reduction! 2. Easily connects to PCs and evaluation equipment via RJ45. - Convert from 1000BASE-T1 to 1000BASE-T - Convert from 100BASE-T1 to 100BASE-TX
	3. Can be powered from a PC via USB.
	4. Easy setup with just a switch. Auto-negotiation, communication speed, master/slave switching (Automatically detects/sets communication speed and method) 5. The status is instantly visible with the LED! Link status, data communication Master/slave status • SQI (Signal Quality Indicator) level ≫Actual intuitive settings and operability, and highly visible status display Watch the video

Product Summary

This product is a Media Converter (Media Converter) from Macnica technology brand "Mpression" that supports 1000BASE-T1 and 100BASE-T1, equipped with Broadcom's BCM89883 chip compliant with the automotive Ethernet standards IEEE802.3bp/802.3bw. For instructions on how to use it, please click here.
This product is also being used in demonstration experiments of Single Pair Ethernet, a communication technology that enables communication and power supply using a single pair of signal lines (one pair of conductors).
*For more details on the Single Pair Ethernet Consortium (SPEC), please click here.

There are two models available.

① [1000BASE-T1 Media Converter]This single device is all you need for future Ethernet speed increases. A type that supports both 1Gbps and 100Mbps is recommended!
This jig can convert an ECU (evaluation target) equipped with 1000BASE-T1 (Open Alliance BroadR-Reach, hereafter OABR) to 1000BASE-T, enabling operation at 1Gbps.
This jig converts an ECU (evaluation target) equipped with 100BASE-T1 (OABR) to 100BASE-TX, and can also operate at 100Mbps.

② [100BASE-T1 Media Converter]
This jig converts an ECU (evaluation target) equipped with 100BASE-T1 (OABR) to 100BASE-TX, enabling operation at 100Mbps.

1000BASE-T1 media converter — ① 1000BASE-T1/100BASE-T1 Media Converter

100BASE-T1 media converter — ② 100BASE-T1 Media Converter

Deliverables

Media Converter main unit (1), USB adapter (1), USB Type-C cable (1)

*OABR communication cables and Ethernet communication cables (CAT5e) must be purchased separately.

*The following products are also available as optional items, so please contact us for details.

- Dedicated unshielded twisted pair (UTP) cable

-Type name: MATEnetAssy1FF_2

-Specifications: With 100/1000BaseT1 connector (both ends female-female) Cable length 1m

Product Specifications

Product Specifications	In-vehicle Ethernet compatible Media Converter (MAC1000T1_MCJ2 / MAC100T1_MCJ2)
External dimensions	Length x Width x Height = (D) 72 mm x (W) 110 mm x (H) 30 mm (excluding switch protrusions)
power supply	+5V DC
Power Consumption	1.5W
interface	Automotive Ethernet 1000BASE-T1/100BASE-T1 * 1port 1000BASE-T/100BASE-TX *1 port

MAC100T1_MCJ2 only supports 100BASE-T1 and 100BASE-TX.

Feature Description

SQI, Master, Slave, LED, MATEnet, Connector, Auto Negotiation, Medicon, Media Converter, RJ-45, Switch — MAC1000T1_MCJ2 Front Panel

	Name	function
1	1000BASE-T1/100BASE-T1 connector (MATEnet)	1000BASE-T1/100BASE-T1 (OABR) interface
2	1000BASE-T/100BASE-TX connector (RJ45)	1000BASE-T/100BASE-TX interface
3	power jack	USB Type-C cable insertion slot
4	T1 Link/Speed/Act display	When link down・・・LED off 1000BASE-T1 (OABR) link-up: green LED lights 100BASE-T1 (OABR) link-up: orange LED lights When sending/receiving data・・・LED blinks
5	Master/Slave display	Master・・・Green LED lights Slave・・・Orange LED lights
6	LAN Link/Speed/Act display	When link down・・・LED off 1000BASE-T link-up: green LED lights up During 100BASE-TX link-up: orange LED lights up When sending/receiving data・・・LED blinks
7	SQI display	LED lights according to SQI value
8	Power switch power ON display	Power ON/OFF changeover slide switch When the power is turned on, the green LED lights up. When the power is off・・・LED off
9	Mode setting switch	A: When ON・・・Auto-Negotiation Enable A: When OFF・・・Auto-Negotiation Disable S: When ON・・・Speed 1000M/100Mbps (when Auto-Negotiation is enabled) Speed 1000Mbps (when Auto-Negotiation is disabled) S: When OFF・・・Speed 100Mbps M: When ON・・・Master M: When OFF・・・Slave

MAC100T1_MCJ2 only supports 100BASE-T1 and 100BASE-TX.

Network configuration diagram

Watch the "Operation Instructions" video (packet conduction, LED operation) [approx. 3 minutes]

Selling price

	product	unit price
１.	MAC1000T1_MCJ2 main unit (USB adapter and USB Type-C cable included)	198,000 yen
2.	Special set price MAC1000T1_MCJ2 + Cable	199,800 yen
3.	MAC100T1_MCJ2 main unit (USB adapter and USB Type-C cable included)	65,000 yen
4.	OABR communication cable only	5,000 yen
