Category

Description

Platform

Qualcomm QCM6125/QCS6125

Kryo260 CPU: 4xGold @ 2.0GHz + 4xSilver @ 1.8GHz

Qualcomm Adreno™ 610 GPU, Adreno DPU 851

Qualcomm Compute DSP with Hexagon Vector eXtensions (dual-HVX512), Audio DSP

Memory and Storage

LPDDR4x 3GB/2GB + eMMC 5.1 32GB

LPDDR4x 4GB+ eMMC 5.1 64G

Connectivity

Wi-Fi 1 × 1 802.11a/b/g/n/ac, Bluetooth 5.0, and FM

WWAN (CM6125 Only)

LTE Cat13 2 × 20 CA at 400 Mbps DL and 150 Mbps UL capability

LTE FDD:B1,B2,B3,B4,B5,B7,B8,B12,B13,B17,B18,B19,B20,B25,B26,B28(A+B),B66,B71

LTE TDD: B34,B38,B39,B40,B41

WCDMA:B1,B2,B4,B5,B6,B8,B19

GSM:850/900/1800/1900MHz

＊SKUにより異なります。詳細はお問合せください。

GNSS (CM6125 Only)

Gen 9 VT2; GPS, GLONASS, BeiDou, Galileo, QZSS, and SBAS

Video Encode

4K@30fps/1080@120fps (H.265/H.264/VP8)

Video Decode

4K@30fps/1080P@120fps (H.265/H.264/VP8/VP9)

Display Interfaces

One 4-lane; DSI D-PHY 1.2, Split link supported, Up to FHD+ (1080 × 2520)@60fps;

One DisplayPort 1.4 over Type-C (external)

Camera Interfaces

2x ISP 14 bit: 16 + 16 MP, and 25 MP @30 fps ZSL

MIPI combination D-PHY 1.2 /C-PHY 1.0 configurable in 4/4/4 or 4/4/2/1

Other Interfaces

1 x Slimbus; 1 x Soundwire; 1 x USB 3.0 with DP/1 x USB 2.0; 1 x SD Card; 5 x I2S; 10 x QUP; 2 x UIM; GPIOs

Operating Environment

Operation Temperature: -25℃ ~ +75℃

Operation Humidity: 5%~95%, non-condensing

Voltage

3.2V ~ 4.6V

Dimension

CM6125: 35mm x 51mm x 2.9mm, Modem Version

C6125: 35mm x 34mm x 2.9mm, Wi-Fi Version

OS Support

Android
