Category

   Item

   Description

   Platform

   Chipset

   Qualcomm® Snapdragon™ 845 processor

   CPU

   64-bit applications processor (Kryo 385) with 2 MB L3 cache;
   Quad high-performance Kryo™ cores 2.649 GHz - Kryo™ Gold cluster with 256 kB L2 cache per core,
   Kryo™ Gold single- core boost at 2.803 GHz;
   Quad low - power Kryo™ cores at 1.766 GHz - Kryo™ Silver cluster with 128 kB L2 cache per core

   GPU

   Qualcomm® Adreno™630 graphics processing unit(GPU) 4K 60 fps or 2 ⅹ2k 90 fps
   OpenGL™ ES 3.2 + AEP , DX next, Vulkan^® 1.1
   OpenCL™ 2.0 full profile, RenderScript

   DSP

   Compute DSP with Qualcomm®Hexaron™Vector
   Extensions (HVX) processor

   OS

   Android / Linux

   Memory and Storage

   LPDDR4x 4GB + UFS 64GB

Multimedia

   Display

   2x MIPI-DSI 4-lane, Up to 3840*2400@60fps

   Camera

   Qualcomm® Spectra™ 280 ISP: Support 3 x 4-lane MIPI_CSI + 1 x 2-lane MIPI_CSI, Dual 14-bit ISP + one Lite ISP, up to 32MP

   Decode

   4K60 decode for H.264 High Profile, H.265 Main 10 PROFILE and VP9 Profile 2

   Encode

   4K60 encode for H.264 High Profile,
   H.265 Main 10 Profile ; 4K30 encode for VP8

Connectivity

   WIFI/BT

   802.11a/b/g/a/n/ac 2ⅹ2 MIMO&BT 5.0 with BLE

 Interface

   Interface

   USB3.1 x 2;  PCIe2.1 x 1; PCIe3.0 x 1; SDIO 3.0ⅹ1;
   TF card x 1; QUP for UART/I2C/SPI x 5, GPIO x8, MI2S x4;

Dimension

   Size

   60mm x 37mm x 6.4mm

System
Environment

   Power

   +3.8V/3A Input

   Operating Temp

   -20°C ~ 70°C

   Storage Temp

   -40°C ~ 70°C

   Relative Humidity

   5 to 95% non-condensing
