Product

IQ-615

CPU Architecture

64-bit Octa-Core

CPU Cores

2x Kryo4 Gold @ 1.9 GHz + 6x Kyro4 Silver-lite @ 1.6 GHz

Memory Architecture

2x 16-bit LPDDR4x 1555 MHz, up to 8 GB

GPU

Adreno 612 GPU

Video Decode

4K 60fps 10-bit: HEVC/H.265, 8-bit VP9, VP8, and H.264

Video Encode

1080p 60fps, 8-bit: HEVC/H.265, H.264, and VP8

Video Decode + Encode

4K 30fps Decode + 1080p 30fps Encode

Display Resolutions

Up to a maximum of 5 MP, e.g.: 2x 1920x1080 @ 60fps (FHD) + 1x 1280x720 @ 60fps

Display Interfaces

1x 4-lane MIPI DSI-2 + 1x DP v1.4 (supports: SST and MST)

Camera Lanes

Up to 6 cameras over 3x 4-lane MIPI CSI-2 v1.3 (D-PHY 1.2, C-PHY 1.0)

Audio DSP

Hexagon QDSP6 v66K @ 1.0 GHz

Audio Interfaces

Up to 5x I2S/PCM/TDM, 2x SLIMbus

Ethernet

1x RGMII / RMII with MDIO GB ETH AVB (1V8 only)

PCIe

1-lane PCIe Gen 2 RC / EP

USB

1x USB 3.1 Gen 1 (SS), 1x USB 2.0 (HS) OTG

Secure Digital Interfaces

1x 4-bit SD/SDIO 3.0 (UHS-I), 1x 8-bit eMMC 5.1, 1-lane UFS2.1 Gear3 (1-lane UFS3.1 can be supported with UFS2.1 feature set), QSPI for boot

Software-Defined Radio

2x high-speed I2S

Multiport SPI / I2C / UART

Up to 14x 4-wire QUPv3 (UART, I2C, SPI)

GPIOs

100+ GPIOs

Compute DSP

Hexagon QDSP6 v66A @ 1.1 GHz, 2x HVX (vector extensions)

Connectivity

Optional: Wi-Fi 6E 802.11ax 2x2 Dual MAC DBS + Bluetooth 5.3. Tri-band support of 2.4GHz, 5GHz, and 6GHz

Temperature Range

-40°C to +105°C

Operating System

Linux Yocto, Ubuntu

Build Design

23 mm x 23 mm, 0.8 mm ball pitch
