車載用 低・中耐圧MOSFET製品概要
インフィニオン社では、低・中・高耐圧のAEC-Q101に準拠した車載用MOSFETのラインナップを取り揃えております。
最大動作温度175℃対応品となり、特定のアプリケーションに縛られず、幅広くご検討いただけます。特に最新のテクノロジーのOptiMOS™ 7は、革新的で堅牢なパッケージと最小の実装面積の組み合わせにより、大電流アプリケーション向けに最高の電力効率、スイッチング損失の低減、SOAの向上を実現します。
また、インフィニオン社の幅広い車載用MOSFETではさまざまなパッケージのラインナップを取り揃えており、 アプリケーションのニーズに応じて要件に合ったシングル、デュアル、ハーフブリッジ、および上面冷却パッケージもご検討いただけます。インフィニオン社の車載用MOSFETは2010年より累計220億個以上の出荷実績があり、非常に高い品質とともに世界No.1のシェアを誇ります。
このページでは低・中耐圧の40V～120V耐圧のラインナップを紹介しております。
製品特徴
- トレンチテクノロジーで業界をリードするRds(on)性能
- 標準パッケージで最高の電流能力を実現
- 最小のスイッチング損失と導通損失
- 堅牢なパッケージテクノロジー
- 幅広いパッケージのラインナップ
- 非常に優れた品質
車載用 低・中耐圧 MOSFETのパッケージラインナップ
本ページで紹介している製品は既にリリースされた製品のみとなり、その他に開発中の新製品もございますので、下記よりお問い合わせください。
40V耐圧
最新のOptiMOS™ 7のテクノロジーを用いた車載用40V耐圧シリーズは、クラス最高のFOM、スイッチング性能、より低いパッケージ抵抗およびインダクタンスを提供します。
40V耐圧のラインナップには、シングルチャンネル、デュアルチャンネル、ハーフブリッジ構成の製品など、幅広いパッケージラインナップで展開しております。
S3O8
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IPZ40N04S5L-2R8 | 40 | 2.8 | PG-TSDSON-8 | S3O8 |
| IPZ40N04S5-3R1 | 40 | 3.1 | PG-TSDSON-8 | S3O8 |
| IPZ40N04S5L-3R6 | 40 | 3.6 | PG-TSDSON-8 | S3O8 |
| IPZ40N04S5-3R9 | 40 | 3.9 | PG-TSDSON-8 | S3O8 |
| IPZ40N04S5L-4R8 | 40 | 4.8 | PG-TSDSON-8 | S3O8 |
| IPZ40N04S5-5R4 | 40 | 5.4 | PG-TSDSON-8 | S3O8 |
| IPZ40N04S5L-7R4 | 40 | 7.4 | PG-TSDSON-8 | S3O8 |
| IPZ40N04S5-8R4 | 40 | 8.4 | PG-TSDSON-8 | S3O8 |
SSO10T（Top Side Cooling）
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUCN04S6N007T | 120 | 0.75 | PG-LHDSO-10 | SSO10T |
| IAUCN04S6N009T | 120 | 0.9 | PG-LHDSO-10 | SSO10T |
| IAUCN04S6N013T | 120 | 1.32 | PG-LHDSO-10 | SSO10T |
| IAUCN04S6N017T | 120 | 1.73 | PG-LHDSO-10 | SSO10T |
SSO8 シングルチャンネル
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUCN04S7L004 | 175 | 0.42 | PG-TDSON-8 | Single SSO8 |
| IAUCN04S7N004 | 175 | 0.44 | PG-TDSON-8 | Single SSO8 |
| IAUCN04S7L005 | 175 | 0.52 | PG-TDSON-8 | Single SSO8 |
| IAUCN04S7N005 | 175 | 0.55 | PG-TDSON-8 | Single SSO8 |
| IAUCN04S7L006 | 175 | 0.6 | PG-TDSON-8 | Single SSO8 |
| IAUCN04S7N006 | 175 | 0.63 | PG-TDSON-8 | Single SSO8 |
| IAUCN04S7L009 | 175 | 0.91 | PG-TDSON-8 | Single SSO8 |
| IAUCN04S7N009 | 175 | 0.96 | PG-TDSON-8 | Single SSO8 |
| IAUCN04S7L011 | 120 | 1.2 | PG-TDSON-8 | Single SSO8 |
| IAUCN04S7N012 | 120 | 1.2 | PG-TDSON-8 | Single SSO8 |
| IAUCN04S7L014 | 120 | 1.43 | PG-TDSON-8 | Single SSO8 |
| IAUCN04S7N015 | 120 | 1.53 | PG-TDSON-8 | Single SSO8 |
| IAUCN04S7L019 | 120 | 1.91 | PG-TDSON-8 | Single SSO8 |
| IAUCN04S7L028 | 100 | 2.8 | PG-TDSON-8 | Single SSO8 |
| IAUCN04S7N020 | 120 | 2.82 | PG-TDSON-8 | Single SSO8 |
| IAUCN04S7N030 | 100 | 3.02 | PG-TDSON-8 | Single SSO8 |
| IAUC80N04S6L032 | 80 | 3.2 | PG-TDSON-8 | Single SSO8 |
| IAUC80N04S6N036 | 80 | 3.6 | PG-TDSON-8 | Single SSO8 |
| IAUC60N04S6L039 | 60 | 3.9 | PG-TDSON-8 | Single SSO8 |
| IAUC60N04S6N044 | 60 | 4.4 | PG-TDSON-8 | Single SSO8 |
SSO8（デュアルチャンネル）
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUCN04S7N040D | 60 | 4.04 | PG-TDSON-8 | Dual SSO8 |
| IAUCN04S7L053D | 60 | 5.34 | PG-TDSON-8 | Dual SSO8 |
| IAUCN04S7N056D | 60 | 5.59 | PG-TDSON-8 | Dual SSO8 |
| IPG20N04S4L-07A | 20 | 7.2 | PG-TDSON-8 | Dual SSO8 |
| IPG20N04S4L-08A | 20 | 8.2 | PG-TDSON-8 | Dual SSO8 |
| IPG20N04S4-09A | 20 | 8.6 | PG-TDSON-8 | Dual SSO8 |
| IPG20N04S4L-11A | 20 | 11.6 | PG-TDSON-8 | Dual SSO8 |
| IPG20N04S4L-18A | 20 | 18 | PG-TDSON-8 | Dual SSO8 |
| IPG20N04S4-18A | 20 | 18.4 | PG-TDSON-8 | Dual SSO8 |
SSO8 （ハーフブリッジ）
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUC60N04S6L030H | 60 | 3 | PG-TDSON-8 | Dual SSO8 HB |
| IAUC60N04S6N031H | 60 | 3.1 | PG-TDSON-8 | Dual SSO8 HB |
| IAUC60N04S6L045H | 60 | 4.5 | PG-TDSON-8 | Dual SSO8 HB |
| IAUC60N04S6N050H | 60 | 5 | PG-TDSON-8 | Dual SSO8 HB |
| IAUC45N04S6L063H | 45 | 6.3 | PG-TDSON-8 | Dual SSO8 HB |
| IAUC45N04S6N070H | 45 | 7 | PG-TDSON-8 | Dual SSO8 HB |
sTOLL
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUAN04S7N004 | 280 | 0.39 | PG-HSOF-5 | sTOLL |
| IAUAN04S7N005 | 250 | 0.51 | PG-HSOF-5 | sTOLL |
| IAUAN04S7N006 | 250 | 0.57 | PG-HSOF-5 | sTOLL |
| IAUAN04S7N007 | 200 | 0.72 | PG-HSOF-5 | sTOLL |
| IAUAN04S7N008 | 180 | 0.82 | PG-HSOF-5 | sTOLL |
TOLL
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IPLU300N04S4-R8 | 300 | 0.77 | PG-HSOF-8 | TOLL |
| IPLU300N04S4-1R1 | 300 | 1.15 | PG-HSOF-8 | TOLL |
| IPLU250N04S4-1R7 | 250 | 1.7 | PG-HSOF-8 | TOLL |
60V耐圧
主に24Vバッテリー環境を想定した60V耐圧の車載用MOSFETは従来の製品に加え、さらに新しいテクノロジーを用いた小型のS3O8、SSO8、大電流向けのTOLG、TOLL、TOLTのパッケージのラインナップが増えました。商用車、建設機械、農業機械などのアプリケーションに幅広くご検討いただけます。
S3O8
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUZ40N06S5L050 | 40 | 5 | PG-TSDSON-8 | S3O8 |
| IAUZ40N06S5N050 | 40 | 5 | PG-TSDSON-8 | S3O8 |
| IAUZ40N06S5N105 | 40 | 10.5 | PG-TSDSON-8 | S3O8 |
| IAUZ30N06S5L140 | 30 | 14 | PG-TSDSON-8 | S3O8 |
SSO8（シングルチャンネル）
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUC120N06S5L011 | 120 | 1.1 | PG-TDSON-8 | Single SSO8 |
| IAUC120N06S5N011 | 120 | 1.12 | PG-TDSON-8 | Single SSO8 |
| IAUC120N06S5L015 | 120 | 1.5 | PG-TDSON-8 | Single SSO8 |
| IAUC120N06S5N017 | 120 | 1.7 | PG-TDSON-8 | Single SSO8 |
| IAUC120N06S5N022 | 120 | 2.2 | PG-TDSON-8 | Single SSO8 |
| IAUC120N06S5L022 | 120 | 2.2 | PG-TDSON-8 | Single SSO8 |
| IAUC120N06S5L032 | 120 | 3.2 | PG-TDSON-8 | Single SSO8 |
| IAUC120N06S5N032 | 120 | 3.2 | PG-TDSON-8 | Single SSO8 |
| IAUC60N06S5N074 | 60 | 5 | PG-TDSON-8 | Single SSO8 |
| IAUC60N06S5L073 | 60 | 7.3 | PG-TDSON-8 | Single SSO8 |
| IAUC41N06S5L100 | 41 | 10 | PG-TDSON-8 | Single SSO8 |
| IAUC41N06S5N102 | 41 | 10.2 | PG-TDSON-8 | Single SSO8 |
SSO8（デュアルチャンネル）
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IPG20N06S4L-11A | 20 | 11.2 | PG-TDSON-8 | Dual SSO8 |
| IPG20N06S4L-14A | 20 | 13.7 | PG-TDSON-8 | Dual SSO8 |
| IPG20N06S4L-26A | 20 | 26 | PG-TDSON-8 | Dual SSO8 |
TOLL / TLOG / TOLT（Top Side Cooling）
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUTN06S5N008 | 510 | 0.76 | PG-HSOF-8 | TOLL |
| IAUTN06S5N008G | 504 | 0.78 | PG-HSOG-8 | TOLG |
| IAUTN06S5N008T | 503 | 0.79 | PG-HDSOP-16 | TOLT |
80V耐圧
主に48Vバッテリー環境を想定した80V耐圧の車載用MOSFETは従来の製品に加え、さらに新しいテクノロジーを用いた小型のS3O8、SSO8、sTOLL、大電流向けのmTOLG、TOLG、TOLL、TOLTのパッケージのラインナップが増え、最大300Aまで流すことができます。
S3O8
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUZ40N08S5N100 | 40 | 10 | PG-TSDSON-8 | S3O8 |
| IAUZ30N08S5N186 | 30 | 18.6 | PG-TSDSON-8 | S3O8 |
| IAUZ20N08S5L300 | 20 | 30 | PG-TSDSON-8 | S3O8 |
SSO8（シングルチャンネル）
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUCN08S7N013 | 175 | 1.3 | PG-TDSON-8 | Single SSO8 |
| IAUC100N08S5N031 | 100 | 3.1 | PG-TDSON-8 | Single SSO8 |
| IAUC100N08S5N034 | 100 | 3.4 | PG-TDSON-8 | Single SSO8 |
| IAUC100N08S5N043 | 100 | 4.3 | PG-TDSON-8 | Single SSO8 |
| IAUC70N08S5N074 | 70 | 7.4 | PG-TDSON-8 | Single SSO8 |
| IAUC64N08S5L075 | 64 | 7.5 | PG-TDSON-8 | Single SSO8 |
| IAUC50N08S5L096 | 50 | 9.6 | PG-TDSON-8 | Single SSO8 |
| IAUC50N08S5N102 | 50 | 10.2 | PG-TDSON-8 | Single SSO8 |
| IAUC28N08S5L230 | 28 | 23 | PG-TDSON-8 | Single SSO8 |
sTOLL
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUA250N08S5N018 | 250 | 1.8 | PG-HSOF-5 | sTOLL |
| IAUA220N08S5N021 | 220 | 2.1 | PG-HSOF-5 | sTOLL |
| IAUA180N08S5N026 | 180 | 2.6 | PG-HSOF-5 | sTOLL |
mTOLG
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUMN08S5N012G | 300 | 1.2 | PG-HSOG-4 | mTOLG |
| IAUMN08S5N013G | 250 | 1.3 | PG-HSOG-4 | mTOLG |
TOLL
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUT300N08S5N011 | 300 | 1.1 | PG-HSOF-8 | TOLL |
| IAUTN08S5N012L | 300 | 1.15 | PG-HSOF-8 | TOLL |
| IAUT300N08S5N012 | 300 | 1.2 | PG-HSOF-8 | TOLL |
| IAUT300N08S5N014 | 300 | 1.4 | PG-HSOF-8 | TOLL |
| IAUT240N08S5N019 | 240 | 1.9 | PG-HSOF-8 | TOLL |
| IAUT200N08S5N023 | 200 | 2.3 | PG-HSOF-8 | TOLL |
| IAUT165N08S5N029 | 165 | 2.9 | PG-HSOF-8 | TOLL |
TOLG
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUS300N08S5N011 | 300 | 1.1 | PG-HSOG-8 | TOLG |
| IAUS300N08S5N012 | 300 | 1.2 | PG-HSOG-8 | TOLG |
| IAUS300N08S5N014 | 300 | 1.4 | PG-HSOG-8 | TOLG |
| IAUS240N08S5N019 | 240 | 1.9 | PG-HSOG-8 | TOLG |
| IAUS200N08S5N023 | 200 | 2.3 | PG-HSOG-8 | TOLG |
| IAUS165N08S5N029 | 165 | 2.9 | PG-HSOG-8 | TOLG |
TOLT（Top Side Cooling）
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUS300N08S5N011T | 300 | 1.1 | PG-HDSOP-16 | TOLT |
| IAUS300N08S5N012T | 300 | 1.2 | PG-HDSOP-16 | TOLT |
| IAUS300N08S5N014T | 300 | 1.4 | PG-HDSOP-16 | TOLT |
100V耐圧
主に48Vバッテリー環境を想定した100V耐圧の車載用MOSFETは従来の製品に加え、さらに新しいテクノロジーを用いた小型のS3O8、SSO8、sTOLL、大電流向けのmTOLG、TOLG、TOLL、TOLTのパッケージのラインナップが増え、最大300Aまで流すことができます。
S3O8
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUZ40N10S5L120 | 40 | 12 | PG-TSDSON-8 | S3O8 |
| IAUZ40N10S5N130 | 40 | 13 | PG-TSDSON-8 | S3O8 |
| IAUZ30N10S5L240 | 30 | 24 | PG-TSDSON-8 | S3O8 |
| IAUZ18N10S5L420 | 18 | 42 | PG-TSDSON-8 | S3O8 |
SSO8（シングルチャンネル）
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUCN10S7N021 | 175 | 2.1 | PG-TDSON-8 | Single SSO8 |
| IAUC100N10S5L040 | 100 | 4 | PG-TDSON-8 | Single SSO8 |
| IAUC100N10S5N040 | 100 | 4 | PG-TDSON-8 | Single SSO8 |
| IAUC100N10S5L054 | 100 | 5.4 | PG-TDSON-8 | Single SSO8 |
| IAUC90N10S5N062 | 90 | 6.2 | PG-TDSON-8 | Single SSO8 |
| IAUC60N10S5L110 | 60 | 11 | PG-TDSON-8 | Single SSO8 |
| IAUC26N10S5L245 | 26 | 24.5 | PG-TDSON-8 | Single SSO8 |
| IAUC24N10S5L300 | 24 | 30 | PG-TDSON-8 | Single SSO8 |
SSO8（デュアルチャンネル）
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IPG20N10S4L-22A | 20 | 22 | PG-TDSON-8 | Dual SSO8 |
| IPG20N10S4L-35A | 20 | 35 | PG-TDSON-8 | Dual SSO8 |
| IPG20N10S4-36A | 20 | 36 | PG-TDSON-8 | Dual SSO8 |
| IPG16N10S4L-61A | 16 | 61 | PG-TDSON-8 | Dual SSO8 |
| IPG16N10S4-61A | 16 | 61 | PG-TDSON-8 | Dual SSO8 |
sTOLL
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUA210N10S5N024 | 210 | 2.4 | PG-HSOF-5 | sTOLL |
| IAUA180N10S5N029 | 180 | 2.9 | PG-HSOF-5 | sTOLL |
| IAUA170N10S5N031 | 170 | 3.1 | PG-HSOF-5 | sTOLL |
mTOLG
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUMN10S5N016G | 220 | 1.6 | PG-HSOG-4 | mTOLG |
| IAUMN10S5N017G | 200 | 1.6 | PG-HSOG-4 | mTOLG |
TOLL
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUT300N10S5N014 | 300 | 1.4 | PG-HSOF-8 | TOLL |
| IAUT300N10S5N015 | 300 | 1.5 | PG-HSOF-8 | TOLL |
| IAUT260N10S5N019 | 260 | 1.9 | PG-HSOF-8 | TOLL |
| IAUT150N10S5N035 | 150 | 3.5 | PG-HSOF-8 | TOLL |
TOLG
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUS300N10S5N014 | 300 | 1.4 | PG-HSOG-8 | TOLG |
TOLT（Top Side Cooling）
| Product | ID @25°C max [A] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUS300N10S5N015T | 300 | 1.5 | PG-HDSOP-16 | TOLT |
| IAUS260N10S5N019T | 300 | 1.9 | PG-HDSOP-16 | TOLT |
120V耐圧
高電圧バッテリーからの降圧DCDCコンバーターなどのアプリケーションへの使用を想定した120V耐圧の車載用MOSFETの新製品が追加されました。TOLG、TOLL、TOLTのパッケージのラインナップにより、最大120Aまで流すことができます。
TOLL / TLOG / TOLT（Top Side Cooling）
| Product | VDS max [V] | RDS (on) @10V max [mΩ] | Infineon Package name | Standard Package name |
| IAUTN12S5N017 | 120 | 1.7 | PG-HSOF-8 | TOLL |
| IAUTN12S5N018G | 120 | 1.8 | PG-HSOG-8 | TOLG |
| IAUTN12S5N018T | 120 | 1.8 | PG-HDSOP-16 | TOLT |
