WAVESHAPERS
WaveShaperは、プログラム可能な光学フィルターと、光学スイッチを搭載した機器で、入力光をコントロールすることができます。
対応している波長帯域や、入出力のポート数で、多くのバリエーションがあります。
以下に主な機能をいくつか紹介いたします。(できる機能は機種によりますので、より詳細はお問い合わせください。)
機能
任意スペクトル形状のフィルタリング
帯域幅やスペクトルの形状を任意に設定することができます。

Mux/DeMuxおよびDe-/Interleaving
チャネルを自由にプログラムできるMux/DeMux、およびDe-/Interleaverとして動作します。

疑似変調スペクトルの生成
変調されているかのような形状のスペクトルを生成することができます。アンプなどを含んだ光学系の評価に有用です。

その他の機能
・分散補償
・レーザパルスの圧縮、整形、生成
・ゲイン等化
・入力光を複数に分ける分配器
・プログラマブル干渉計
・イーサネット経由で遠隔モニター
スペック
WAVESHAPER Specifications
Model |
100A |
500A |
16000A |
1000A/SP (1) |
500A/L |
1000A/L, 4000A/L |
1000A/S, 4000A/S |
1000A/U (6), 4000A/U (6) |
||
---|---|---|---|---|---|---|---|---|---|---|
Wavelength Band |
C-Band |
L-Band |
S-Band |
U-Band |
||||||
Optical Ports | Port Configurations |
1x1 |
1x19, 4x16, 8x12, 10x10 |
1x1 |
1x1, 1x4 |
|||||
Filter Control |
Operating Frequency Range |
191.1 THz to 196.46 THz (1526.0 nm to 1568.7 nm) |
191.250 THz to 196.275 THZ (1527.4 nm to 1567.5 nm) |
186.2 THz to 191.05 THz (1569.2 nm to 1610.0 nm) |
196.2 THz to 204.2 THz (1468.0 nm to 1528.0 nm) |
181.55 THz to 190.25 THz (1575.8 nm to 1651.3 nm) |
||||
Filter Bandwidth |
10 GHz – 1 THz (0.08 – 8 nm) |
10 GHz – 5.36 THz (0.08 – 42.7 nm) |
10 GHz - 5 THz (0.08 nm - 40 nm) |
10 GHz – 4.85 THz (0.08 – 40.8 nm) |
20 GHz - full range (0.16 nm - full range) |
|||||
Filter Shape |
Band-pass, Gaussian |
Arbitrary |
||||||||
Frequency Setting Resolution |
±1 GHz (±8 pm) |
|||||||||
Frequency Setting Accuracy |
±2.5 GHz (±20 pm) |
± 5 GHz |
||||||||
Bandwidth Setting Resolution |
±1 GHz (±8 pm) |
|||||||||
Bandwidth Setting Accuracy |
±5 GHz (±40 pm) |
± 10 GHz |
||||||||
Bandwidth Setting Repeatability |
±2.5 GHz (±20 pm) |
± 5 GHz |
||||||||
Group Delay Control Range |
n/a |
-25 ps to +25 ps |
n/a |
-25 ps to +25 ps |
-15 ps to +15 ps |
|||||
Attenuation Control Range |
n/a |
0 to 35 dB |
||||||||
Attenuation Setting Resolution |
n/a |
0.01 dB |
0.1 dB |
0.01 dB |
||||||
Attenuation Setting Accuracy |
n/a |
±1.0 dB from 0 to 10 dB, ±10 % from 10 to 30 dB |
||||||||
Settling Time |
<500 ms |
|||||||||
Loss andDispersion | Insertion Loss |
< 5 dB (2) |
< 7 dB (3) |
|||||||
Insertion Loss Non-Uniformity |
0.7 dB |
0.7 dB (4) |
1 dB |
|||||||
Polarization Dependent Loss (PDL) |
0.4 dB |
0.5 dB |
n/a |
0.4 dB |
0.8 dB |
|||||
Differential Group Delay (DGD) |
< 0.5 ps |
n/a |
< 0.5 ps |
|||||||
Return Loss |
>25 dB |
|||||||||
OpticalPower (5) | Max Total Input Optical Power |
+27 dBm |
||||||||
Max Optical Power per 50 GHz channel |
+13 dBm |
|||||||||
Environment | Operating Temperature |
Bench-top / Rack-mount instrument: 15 to 35°C Module: 15 to 55°C with airflow of min 1 m / sec across top of module |
||||||||
Operating Humidity |
10 to 90% |
|||||||||
Electrical | Communications Interface |
Ethernet (GbE), USB 2.0 |
||||||||
Power Consumption |
<50 VA |
|||||||||
Mechanical | Connector Interface |
FC/APC |
LC/APC |
FC/APC |
||||||
Dimensions, weight |
Bench-top: 241 mm x 88 mm x 316 mm, 3.8 kg Module: 220 mm x 140 mm x 37 mm, 0.8 kg |
Notes
(1) Measured on signal in slow axis
(2) Valid for Filter Bandwidth settings of 15 GHz and larger. For Filter Bandwidth settings below 15 GHz an additional loss of up to 2 dB may apply.
(3) Valid for Filter Bandwidth settings of 25 GHz and larger. For Filter Bandwidth settings below 25 GHz an additional loss of up to 2 dB may apply.
(4) Specification is valid over the frequency range of 187.0 to 191.05 THz. From 186.35 to 191.05 THz the insertion loss non-uniformity is 1.0 dB max.
(5) Optical signals with spectral components below 600 nm must be avoided.
(6) Optical specifications are guaranteed up to 1649 nm. Above 1649 nm Specifications are met on a best effort basis.
WAVESHAPER® B-SERIES Specifications
The device will meet all specifications following a warm-up period of 10 minutes from a temperature within the Operating Temperature range. Specifications may change without notice.
Model (5) |
1000B/O |
4000B/O |
500B/C |
1000B/C |
4000B/C |
1000B/L |
4000B/L |
1000B/X |
4000B/X |
32000B/C |
32002B/C |
32000B/X |
32002B/X |
|
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Optical Cores |
Single |
Dua |
Single |
Dual |
||||||||||
Transmission Band |
O-band |
Super C-band |
Super L-band |
C+L band |
Super-C |
Super-C + Super-L |
||||||||
Optical Ports | Port Configurations |
1x1 |
1x4 |
1x1 |
1x4 |
1x1 |
1x4 |
1x1 |
1x4 |
1x31, 4x28, 8x24, 12x20, 16x16 |
||||
Filter Contro | Operating Frequency Range |
220.76 THz to 237.20 THz (1264 nm to 1358 nm) |
190.55 THz to 196.775 THz (1523.53 nm to 1573.301 nm) |
184.25 THz to 190.59 THz (1572.97 nm to 1627.10 nm) |
185.85 THz to 197.000 THz (1521.79 nm to 1613.08 nm) |
190.65 THz to 196.65 THz (1524.5 nm to 1572.47 nm |
184.28 THz to 196.8 THz (1523.4 nm to 1626.8 nm) |
|||||||
Filter Bandwidth |
30 GHz to full range |
10 GHz to full range |
10 GHz to full range 8 GHz to full range (1) |
18 GHz to full range 14 GHz to full range (1) |
10 GHz to full range |
|||||||||
Filter Shape |
Arbitrary Attenuation and Arbitrary Phase |
Arbitrary Attenuation |
Arbitrary Attenuation and Arbitrary Phase |
|||||||||||
Frequency Setting Resolution |
0.1 GHz (0.8 pm) |
|||||||||||||
Frequency Setting Accuracy |
±10 GHz (± 60 pm) |
±1.5 GHz (±12 pm) |
±5 GHz (±40 pm) |
±1.5 GHz (±12 pm) |
±5 GHz (±40 pm) |
|||||||||
Bandwidth Setting Resolution |
0.1 GHz (0.8 pm) |
|||||||||||||
Bandwidth Setting Accuracy |
±20 GHz |
±5 GHz (±40 pm) |
±10 GHz (±80 pm) |
|||||||||||
Bandwidth Setting Repeatability |
±5 GHz (± 30 pm) |
±2.5 GHz (±20 pm) |
±5 GHz (±40 pm) |
|||||||||||
Group Delay Control Range |
±20 ps |
Not Applicable |
±25 ps |
±15 ps |
||||||||||
Attenuation Control Range |
0 to 40 dB |
|||||||||||||
Attenuation Setting Resolution |
0.1 dB |
0.01 dB |
||||||||||||
Attenuation Setting Accuracy |
±1 dB for 0.01 to 10 dB ±10% for 10.01 to 25 dB ±15% for 25.01 to 30 dB |
|||||||||||||
Settling Time (Filter update rate) |
<0.1 s (>10 Hz) |
|||||||||||||
Loss andDispersion | Insertion Loss |
8 dB |
5 dB (2) |
5 dB (2) 10 dB (1,2) |
6.5 dB (3) 12 dB (1, 3) |
6.0 dB (premium ports) (6) 8.0 dB (standard ports) |
6.5 dB (premium ports) (6) 9.0 dB (standard ports) |
|||||||
Insertion Loss Non-Uniformity |
0.8 dB |
0.6 dB |
0.8 dB |
1.5 dB |
||||||||||
Polarization Dependent Loss (PDL) |
0.6 dB |
0.4 dB |
0.6 dB |
0.8 dB |
||||||||||
Differential Group Delay (DGD) |
0.5 ps |
0.6 ps |
0.5 ps |
0.5 ps |
||||||||||
Return Loss |
30 dB |
25 dB |
30 dB |
|||||||||||
OpticalPower (4) | Max Total Input Optical Power |
27 dBm |
||||||||||||
Max Optical Power per 50 GHz channel |
13 dBm |
|||||||||||||
Environment | Operating Temperature |
10 to 35 °C |
||||||||||||
Operating Humidity |
10% to 90% non condensing |
|||||||||||||
Electrical | Communications Interface |
USB 2.0, Ethernet (GbE) |
||||||||||||
Power Consumption |
< 50 W |
< 60 W |
||||||||||||
Mechanical | Connector Interface |
FC/APC, FC/UPC |
LC/APC |
|||||||||||
Dimensions |
241 x 88 x 316 ㎣ |
241 x 88 x 375.5 ㎣ |
442 x 88 x 316 ㎣ |
241 x 88 x 375.5 ㎣ |
442 x 88 x 316 ㎣ |
|||||||||
Weight |
3.8 kg |
4.5 kg |
5 kg |
4.5 kg |
5 kg |
Notes:
(1) Valid for port 1 when selecting “High Resolution” mode
(2) Valid for Filter Bandwidth settings of 15 GHz and larger. For Filter Bandwidth settings below 15 GHz an additional loss of up to 2 dB may apply. (3) Valid for Filter Bandwidth settings of 25 GHz and larger. For Filter Bandwidth settings below 25 GHz an additional loss of up to 2 dB may apply. (4) Optical signals with spectral components below 600 nm must be avoided.
(5) Specifications for the WaveShaper 1000B/O, 4000B/O, 32000B and for 32002B are preliminary.
(6) The WaveShaper 32000B and 32002B have at least 10 premium ports which show reduced insertion loss. These will be named in the Certificate of Conformity which comes along with the shipment.
WAVEANALYZERS
WaveAnalyzerは、CバンドまたはLバンドに対応した光スペクトラムアナライザーです。
ディスプレイ一体型のポータブルタイプと、PCをつないで使うベンチトップタイプがあります。
高い分解能(レゾリューション)と速い掃引速度(スイープスピード)が特徴で、例えばWA1500Sでは、分解能=180MHz、掃引速度0.1秒を誇ります。
以下に主な機種を紹介します。詳細はお問い合わせください。
WaveAnalyzer 200A

Cバンドに対応したポータブルタイプの光スペクトラムアナライザーです。
タッチパネルディスプレイで、スマートホンのような感覚で、縦方向(振幅軸)と横方向(周波数軸)を調整することができます。
・対応バンド Cバンド
・分解能 1.75GHz
・スィープ 2回/秒
・電源 バッテリ駆動またはACアダプタ
・イーサネット経由でリモート制御可能
・日本語対応 あり
WaveAnalyzer 200A Specifications
Spectral | Frequency Range | 191.1 to 196.2 THz (1527.8 to 1568.8 nm) |
Spectral Sampling Resolution | 312.5 MHz | |
Resolution Bandwidth (FWHM) | 1.75 GHz (15 pm) | |
Absolute Frequency Accuracy (1) | +/- 1 GHz | |
Frequency Repeatability (sweep to sweep) | 200 MHz | |
Measurement Update Rate Full C-band scan | 2 updates / s (typical) | |
Power | Max Total Power | 27 dBm |
Max Power Density | +11.5 dBm / 1.75 GHz | |
Noise floor | -58.5 dBm / 1.75 GHz | |
Relative Power Accuracy | +/-0.5 dB (2) | |
Mechanical, Electrical andEnvironment | Operating Temperature | 5°C to 35°C |
Operating Humidity | 10% to 85% | |
Communications Interface | Ethernet, USB 2.0 (master) | |
Power Consumption (3) | 100 V - 240 V; 40 VA | |
Connector Type | FC/APC, LC/UPC | |
Size Instrument only instrument including protective bumper |
255 mm x 140 mm x 30 mm 273 mm x 168 mm x 50 mm |
|
Weight Instrument only instrument including protective bumper |
1.25 kg 1.5 kg |
Notes:
(1) Valid within recommended recalibration period
(2) Guaranteed when using an ASE source
(3) Condition: Battery is charging and instrument is operated
WaveAnalyzer 400A

C、Super C、C+Lバンドに対応した、小型ベンチトップタイプの光スペクトラムアナライザーです。
・対応バンド Cバンド、スーパーCバンド、C+Lバンド(型番が異なる)
・分解能 650MHz
・スィープ 2回/秒
・X-Y 2偏波検波可能(コヒーレント検波)
・イーサネット経由でリモート制御可能
WaveAnalyzer 400A Specifications (preliminary)
Specifications are guaranteed except where stated as typical (typ).
WA 400A / C-band |
WA 400A / Super C-band |
WA 400A / C+L band |
||
Spectral | Frequency Range |
191.1 to 196.2 THz (1527.8 to 1568.8 nm) |
190.623 to 196.727 THz (1523.9 to 1572.7 nm) |
186.2 to 196.2 THz (1527.8 to 1610.05 nm) |
Resolution Bandwidth (FWHM) |
650 MHz (typical) |
|||
Absolute Frequency Accuracy (1) |
+/- 1 GHz |
|||
Frequency Repeatability (sweep to sweep) |
200 MHz |
|||
Measurement Update Rate Full scan |
2 updates / s (typical) |
|||
Power | Max Total Power |
26 dBm |
29 dBm |
|
Max Power Density |
+11.5 dBm / 1.75 GHz |
+14.5 dBm / 1.75 GHz |
||
Noise floor |
57.5 dBm / 1.75 GHz |
-54.5 dBm / 1.75 GHz |
||
Relative Power Accuracy |
+/-0.5 dB (2) |
|||
Mechanical,Electrical &Environment | Operating Temperature |
15°C to 35°C |
||
Operating Humidity |
10% to 85% |
|||
Communications Interface |
Ethernet |
|||
Power Consumption |
100 V - 240 V; <20 VA |
|||
Connector Type |
FC/APC, SC/APC |
|||
Size (Benchtop) (width x depth x height) |
221 mm x 221 mm x 44 mm (height with feet: 51 mm) |
|||
Weight |
1.5 kg |
Notes:
(1) Valid within recommended recalibration period
(2) Guaranteed when using an ASE source and setting Resolution Bandwidth to 1.75 GHz
WaveAnalyzer 1500S

C、Lバンドに対応した、ベンチトップタイプの光スペクトラムアナライザーです。リアルタイムかつ超高分解能であり、研究開発に向きます。
・対応バンド Cバンド、Lバンド(型番が異なる)
・分解能 180MHz
・スィープ 4回/秒(200GHz幅の場合10回/秒)
・X-Y 2偏波検波可能(コヒーレント検波)
・イーサネット経由でリモート制御可能
WaveAnalyzer 1500S Specifications
Mode |
WA 1500S / C-Band |
WA 1500S / L-Band |
|
Spectral | Frequency Range |
191.05 to 196.35 THz (1526.8 to 1569.1 nm) |
186.0 to 191.05 THz (1569.1 to 1611.7 nm) |
Spectral Sampling Resolution |
20 MHz |
||
Resolution Bandwidth (FWHM) |
180 MHz (typ.) |
||
Absolute Frequency Accuracy (1) |
+/- 500 MHz |
||
Frequency Repeatability (sweep to sweep) |
50 MHz |
||
Measurement Update Rate (2): Full C- or L-band scan Scan across any 200 GHz window |
4 updates / s 10 updates / s |
||
Power | Max Total Power |
23 dBm (3 dBm for “3 dBm max” optical input) |
|
Max Power Density |
0 dBm / 20 MHz |
||
Relative Power Accuracy |
+/-0.2 dB (4) |
||
Spurious Free Dynamic Range (1) |
> 50 dB |
||
Close-In Dynamic Range (5) |
> 38 dB @ +/- 2 GHz |
||
Mechanical, Electrical and Environment |
Operating Temperature |
15°C to 35°C |
|
Operating Humidity |
10% to 85% |
||
Communications Interface |
USB 2.0, Ethernet |
||
Trigger Input |
TTL (SMA) |
||
Trigger Output |
TTL (SMA) |
||
Power Consumption |
100 V - 240 V; 20 VA |
||
Connector Type |
FC/APC |
||
Size |
241 mm x 88 mm x 316 mm |
||
Weight |
< 4 kg |
Notes:
(1) Valid within recommended recalibration period
(2) Requires a PC with at least an i7 processor or equivalent and a Gigabit Ethernet connection
(3) Specifications valid on the “23 dBm max“ optical port, except where stated differently
(4) Guaranteed when using an ASE source
(5) When measuring on one optical channel
WAVEMAKERS®
WaveMakerは、C、Super C、C+Lバンドに対応した光信号生成器です。
ASE光源に加えて、WaveShaperと同じプログラム可能なフィルターが組み込まれており、出力光のスペクトルをGUIでプログラムすることが可能です。
詳細はお問い合わせください。
Specifications (Preliminary)
Model |
WaveMaker 500A |
WaveMaker 4000A/C |
WaveMaker 4000A/X |
|
Transmission Band |
Super-C Band |
C-band |
C+L-band |
|
External Optical Ports |
Port Configurations |
1 output port |
4 input ports (2), 1 output port |
|
WaveMakerControl | Technology |
Erbium ASE Source plus Erbium Amplifier |
||
Frequency Range |
190.55 THz to 196.775 THz (1523.53 nm to 1573.301 nm) |
191.0 THz to 196.225 THz (1527.8 nm to 1569.5 nm) |
186.20 THz to 196.20 THz (1528.0 nm to 1610.0 nm) |
|
Maximum Output Power |
>20 dBm |
14 dBm |
17 dBm (1) |
|
Maximum Output power density (flat spectrum) |
>13 dBm / THz |
8 dBm / THz |
||
Maximum Output Power – single 100GHz wide channel |
17 dBm |
10 dBm |
||
Blocked Power Density Level |
up to 30 dB (4) |
< -60 dBm / THz |
||
WaveShaper /ProgrammableFilter Control | Frequency Range (2) |
190.55 THz to 196.775 THz (1523.53 nm to 1573.301 nm) |
190.65 THz to 196.65 THz (1524.5 nm to 1572.5 nm) |
185.90 THz to 196.15 THz (1528.4 nm to 1612.65 nm) |
Filter Bandwidth |
10 GHz to full range |
|||
Filter Shape |
Arbitrary Attenuation |
Arbitrary Attenuation and Arbitrary Phase |
||
Frequency Setting Resolution |
±0.1 GHz (±0.8 pm) |
|||
Frequency Setting Accuracy |
±2.5 GHz (±20 pm) |
±1.5 GHz (±12 pm) |
||
Bandwidth Setting Resolution |
±0.1 GHz (±0.8 pm) |
|||
Bandwidth Setting Accuracy |
±5 GHz (±40 pm) |
|||
Bandwidth Setting Repeatability |
±2.5 GHz (±20 pm) |
|||
Group Delay Control Range |
n/a |
±25 ps |
||
Attenuation Control Range |
n/a |
0 to 30 dB |
||
Attenuation Setting Resolution |
n/a |
0.01 dB |
||
Attenuation Setting Accuracy |
n/a |
±1 dB for 0.01 to 10 dB ±10% for 10.01 to 25 dB ±15% dB for 25.01 to 30 dB |
||
Settling Time (Filter update rate) |
<0.1 s (>10 Hz) |
|||
Insertion Loss |
n/a |
<6 dB (3) |
||
Insertion Loss Non-Uniformity |
n/a |
<0.8 dB |
||
Polarization Dependent Loss (PDL) |
n/a |
<0.6 dB |
||
Differential Group Delay (DGD) |
n/a |
0.6 ps |
||
Return Loss |
n/a |
25 dB |
||
Max Total Input Optical Power |
n/a |
27 dBm |
||
Max Optical Power per 50 GHz channel |
n/a |
13 dBm |
||
Environment | Operating Temperature |
15°C to 35°C |
||
Operating Humidity |
10% to 85%, non condensing |
|||
Electrical | Communications Interface |
USB 2.0, Ethernet (GbE) |
||
Voltage |
100-240 V (AC) |
|||
Power Consumption |
<60 VA |
|||
Mechanical | Connector Interface |
FC/APC, LC/UPC |
||
Dimensions, weight |
442 mm x 88 mm x 316 mm, 5 kg |
Notes:
(1) In case signal stretches across C+L band. In case signal covers only C or L band, max power is 14 dBm.
(2) Inserting optical signals with spectral components below 600 nm must be avoided.
(3) Valid for Filter Bandwidth settings of 15 GHz and larger. For Filter Bandwidth settings below 15 GHz an additional loss of up to 2 dB may apply.
(4) Difference of power density levels of a blocked spectral region compared to power density levels in a channel.
