Cato Socket - Easily connect existing LAN environments to SASE. Making the transition to SASE easier
A Cato Socket SD-WAN device connects your physical location to the closest Cato PoP via the last mile connection(s).
お客様は、ファイバー、ケーブル、xDSL、および4G / LTE接続の任意の組み合わせを選択できます。事前にお客さま向けの設定をしてから�出荷しますので、現地でインターネットにWAN設定し、接続、LANに接続し詳細な設定は、Web管理画面でセンターから設定するだけです。
Set up in 3 minutes: We will walk you through setting up Cato socket through the management portal.
Specifications of Cato socket
specification | X1500B | |
housing | ||
size | Width: 18cm x Depth: 13cm x Height: 3cm (Dual rack mount kit sold separately) | |
CPU | Intel® Celeron® Processor N3350 | |
system memory | 4GB DDR 3L 1866MHz | |
storage | 4GB eMMC | |
Ethernet port | 4 x PCIe RJ45 GbE (WAN1/WAN2, LAN1/LAN2) Maximum WAN3 lines | |
USB port | 2 | |
expansion | Harf-card Mini-PCIe slot | |
Serial port | RJ45x1 for system management | |
power supply | 2V DC 24W Adapter included *For overseas shipments, the specified power cable will be included. | |
throughput | Up and down 500Mbps | |
Redundancy | VRRP, PoP automatic connection | |
Factory Default button | 1 | |
authorization | CE/FCC/UL | |
Operating environment | Temperature: 0~40℃ Humidity: 20%~90% RH@55℃ |
specification | X1600 |
housing | |
size | Width: 25.6cm x Depth: 20.0cm x Height: 4.4cm (Rack mount kit and wall mount kit sold separately) |
CPU | Intel®Atom®CPU C3558(4 cores) |
system memory | 4GB |
storage | 16GB eMMC SSD |
Ethernet port | 4 ports X 2.5GbE RJ45 Ports2 ports X 10G SFP+ Ports 2 ports X 1GbE Combo Ports(RJ45/SFP)2 ports X USB3.0 |
USB port | 2 |
CONSOLE port | 2 (RJ45x1/ micro-USB automatic recognition) A LAN cable and Micro USB Type-B (2.0) can be used for the console port, and a "USB Type-A ⇔ Micro USB Type-B (2.0)" cable is included. Masu. |
power supply | +12V DC 60W Adapter *For overseas shipments, the specified power cable will be included. |
throughput | 1Gbps up/down |
Redundancy | VRRP, PoP automatic connection |
Factory Default button | 1 |
Operating environment | Temperature: 0-40℃ (including external power supply) Humidity: 10-95% (no condensation) |
authorization | FCC/CE/CB/UL |
specification | X1700B |
housing | |
housing | 1U |
size | Width: 438mm Depth: 553mm Height: 44mm Includes rack mount kit for X1700B |
CPU | Intel Xeon E-2176G 3.7Ghz CPU / 6cores |
system memory | 16GB DDR4 |
storage | 2×128GB SATA SSD |
Ethernet port | 8 x GbE RJ45 + management port |
extended network | 4×1GbE,2×1Gb Fiber, 2×10Gb Fiber,4x10Gb Fiber |
expansion | 2×PCIe×8 Slots |
USB port | 2(USB3.0) |
Serial port | A LAN cable and Micro USB Type-B (2.0) can be used for the front RJ45x1 system management console port, and a "USB Type-A⇔Micro USB Type-B (2.0)" cable is included. |
USB port | 2(USB3.0) |
power supply | 300W redundant (1+1) *For overseas use, the specified power cable will be included. |
throughput | Up/down 5Gbps |
Redundancy | VRRP, PoP automatic connection |
Factory Default button | 1 |
authorization | CE/FCC/UL |
Cato Socket redundant configuration example
Documents regarding the configuration, connection method, and setup method of Cato Socket are available on the CATO support site.
Cato Socket Maintenance
- Basic send-back maintenance: We will send the device on a first-come, first-served basis after the RMA has been determined. For overseas locations, we will ship directly from CATO's warehouse.
- Domestic on-site maintenance: After RMA judgment, we will replace the local model between 9:00 and 17:00.
- Domestic 24/365 on-site maintenance: After RMA determination, we will replace the local model.
Virtual Sockets
We provide a virtual CATO socket (free of charge) using software. Works on AWS, Azure, and VMware ESXi.
AWS EC2 spec example: Before starting, please let us know your AWS account ID, region, and Amazon AMI.
- 4 vCPU
- 8 GB RAM(8 GiB)
- 4 ENIs(network interfaces)
- Certified instances:
- c5.xlarge
- c5n.xlarge (recommended for sites using bandwidth of 2Gbps or more)
vmware spec example:
- vSphere
- ESX version - ESXi 6.7 or higher
- Image format - OVA
- Virtual machine resources
- 2 vCPUs
- 2 GB RAM (4 GB recommended)
- 7 GB or more HDD
